Panasonic X-L42ET60B

Setting Inspection
Voltage Confirmation
A board
Description Test point Voltage
PANEL12V TP4000 / TP4001 11.5V – 12.5V
SUB5V TP0900 4.95V - 5.4V
SUB3.3V TP5400 3.17V – 3.43V
SUB1.8V TP8714 1.70V – 1.90V
SUB 1.5 V TP8100 1.435V - 1.585V
SUB1.2V TP8101 1.14V - 1.26V
USB5V TP5440 4.94V – 5.40V
DMD_1.2/1.1V TP5703 1.1V – 1.21V
P board
Description Test point Voltage* Voltage**
24V (PANEL) TP7407 and GND TP7414
<1V
24V ± 1.2V
16V TP7410 and GND TP7414
<1V
15.7V ± 0.6V
5VS TP7501 and GND TP7414 5.3V ± 0.2V 5.3V ± 0.2V
PFC TP7202 and GND TP7203***
<340V
390V ± 15V
* Connect AC 230V to JK7101 connector
** Connect DC 2.5V to TV_SUB_ON P2 connector – pin 8 /TP7416/ from voltage divider.
***Beware, for testing of PFC use the GND (TP7203) in Hot area of P board – risk of electric shock!
