DIAGRAM – PROFESSIONAL ARTICULATED HINGE WITH CLOSURE "SOFT"
1
. Unscrew and remove the two screws (1) and loosen the two screws (2). Move the door through
the hole and remove it. Be careful to hold the door securely and place it on a padded surface
to prevent damage.
2. Remove the screws (2). Remove the covers on the opposite side of the cabinet and use them
to cover the holes in these screws.
3. On the opposite side, screw the screws (2) half way.
4. Place the new door on the opposite side, moving the hinge hole by the screws (2). Level and
tighten both screws firmly.
5. Finally, screw the screws firmly (1)
ATTENTION
Be very careful with
articulated hinges. The hinge closes automatically and there are many pinch
points before / during installation
