Pando PVMAV 45-18 - Optional Glass Plinth Installation; Optional Bordeaux Bottle Holder

INOXPAN S.L. WINE CABINETS
18
3.9. GLASS PLINTH (OPTIONAL)
Only for models:

PBE 182-190CRR

PBE 89-66CRR
1
21
1
2
3
1. Unscrew and remove the four screws (2) that are used to fix the metal ventilation plinth (1)
and the bottom bracket. (Fig. 1)
2. Insert the tabs on the glass fronted plinth section into the top slots of the metal plinth.
Manoeuvre the plinth so that the holes in the inner lip of the glass fronted plinth section are
level with the holes in the metal plinth. Re-fit the screws (2). (Fig. 2)
NOTE: Do not tilt the appliance further than 90° during this process. Allow the appliance to settle
for at least 8 hours before switching on after tilting.
3.10. BORDEAUX BOTTLE HOLDER
Only for models:

PBE 182-190CRR
The wine cabinet is designed to load either Bordeaux bottles or Burgundy bottles. In order to
keep the bottle stability when loading the Bordeaux bottles, pls follow up below instruction to
install the plastic Bordeaux bottle holders (if they are provided) on the side pilasters. When
loading the Burgundy bottles, pls remove them.
1 2
