Panduit MP200 Firmware Update Instruction Manual

DWG# 1005977 rAA
5
Troubleshoot Update Errors
Error Messages Troubleshooting
Check if the printer is in the “update” mode.
>> Put the MP200 into “update” mode
Check if the USB cable is firmly connected to the
printer and the computer. Then retry the update.
>> Update the firmware
MP200 is not connected. Put your MP200 into “update”
mode, and then connect it to the computer.

Panduit MP200 Specifications

General

Color	No
Printing colors	Black
Print technology	-
Maximum resolution	180 x 180 DPI
Wire wrap printing	Yes
Maximum printing width	25.4 mm
Ribbon width	24 mm
Ribbon length	7 m
Connectivity technology	Wired & Wireless
Display	LCD
Control type	Buttons
Keyboard layout	QWERTY
Battery type	Built-in battery

Weight and Dimensions

Depth	298 mm
Width	136 mm
Height	90 mm
