High low speed lever (7) have 3 positions A, Neutral and B.
Position A will be give low speed range and position B will be give high
speed range. For engaging this lever. First of all pull lever out side to
disengage locking pin from head stock body and than rotate lever to
your desire position A or B and again engage locking pin in head stock
body. This locking pin will give positive positioning of lever.
Feed direction changing lever (8) have 3 position Reverse,
Neutral, Forward. You can select any position by rotating this lever.
Oil sight glass (11) is provided to cheek the oil level in side the
head stock. Lubrication of main bearings, gears, shifters and bushes are
done by splash lubrication system. It is necessary to keep always proper
oil level in head stock to give lubrication to main bearings and gears.
Oil drain plug (12) is given at back side of the head stock bottom
face to remove or drain lubricating oil from head stock.
Oil filling plug (10) is given on top cover of head stock to add the
lubricating oil inside the head stock.
For removing chuck form A2 Size 4 type main spindle nose, first
remove chuck from back plate. Then remove back plate from main
spindle nose. For mounting chuck reverse procedure given above.
CAUTION : Do not shift gear while M/c is running.
