Lubrication in headstock and Norton gearbox are done by splash
lubrication. Oil level indicator is provided in headstock and Norton
gearbox. Check oil level through oil level indicator regularly. If oil level
seems down in headstock, then pour oil through oil filling plug.
In initial period, for the first time running oil should be changed
after first 300 running hours and then after 500 running hours.
Latter on oil can be used up to 1000 to 1500 running hours. Before
filling new oil, the head stock should be washed with kerosene and
thoroughly dried. Quantity of oil and type of oil to be used in head stock
and Norton gearbox is shown in lubrication chart given in Introduction
section on Page no.16
Lubrication of Apron, Slides, Lead Screw and tail stock are done
by oil can. Various oil holes are provided for lubrication purpose. Dirt,
chips should be brushed away before oiling to prevent them from
entering in to the oil holes.
Apron 2oil holes are given on carriage.
Carriage 2oil holes are given on carriage.
Lead screw support 1oil hole is given on end bracket.
Surface screw 1oil hole is given on carriage.
Compound Slide 1oil hole is given on compound slide.
Tail stock sleeve 2oil holes are given on tail stock body.
Tail stock screw 1oil hole is given on tail stock screw boss.
PANTHER
MODEL PAGE NO.
1350 / 1650 22
