5.3 CARRIAGE AND TOOL POST SUB ASSEMBLY
PANTHER
MODEL PAGE NO.
1350/1650 64
Part No. Part Name Quantity
3001 Saddle 1
3002 Idler gear stud 1
3003 Collar for idler gear stud 1
3004 Idler gear 21 Teeth 1
3005 Rear collar for idler gear 1
3006 Cross slide screw 1
3007 Gear for cross slide screw 16 Teeth 1
3008 Cross slide screw plate 1
3009 Cross slide micro ring 1
3010 Cross slide hand wheel 1
3011 Handle 1
3012 Saddle front lock piece 2
3013 Saddle rear pous 1
3014 Saddle lock bolt 1
3015 Cross slide 1
3016-0 Cross slide screw nut 1
3016-1 Backlash adjustment nut 1
3016-2 Lock nut 1
3017 Cross slide pous 1
3018-0 Cross slide swivel washer 1
3018-1 Stud for C.S.S. washer 1
3019 Swivel saddle 1
3020 Swivel saddle pous 1
3021 Tool post slide screw nut 1
3022 Tool post slide 1
3023 Index ring 1
3024-0 Tool post stud 1
3024-1 Nut for tool post index ring 2
3025 Tool post slide screw 1
