1350 / 1650 7
Descriptions
MODEL
1350/1 1350/2 1650/1 1650/2
No. of module
threads.
44 44 44 44
Range of module
threads.
0.187-3 mod 0.187-3 mod 0.187-3 mod
0.187-3
mod
No. of feeds.
65 65 65 65
Range of long. Feeds.
0.05-0.8
mm/Rev.
0.05-0.8
mm/Rev.
0.05-0.8
mm/Rev.
0.05-0.8
mm/Rev.
Range of Trans.
Feeds.
0.03-0.48
mm/Rev.
0.03-0.48
mm/Rev.
0.03-0.48
mm/Rev.
0.03-0.48
mm/Rev.
Lead screw.
Dia. 31.75
4 TPI or
6 mm pitch
Dia. 31.75
4 TPI or
6 mm pitch
Dia. 31.75 4
TPI or 6
mm pitch
Dia. 31.75
4 TPI or
6 mm pitch
Feed shaft.
19 mm 19 mm 19 mm 19 mm
Tall stock quill Dia.
45 mm 45 mm 45 mm 45 mm
Taper in tail stock
quill.
MT 4 MT 4 MT 4 MT 4
Cross slide travel.
210 mm 210 mm 250 mm 250 mm
Compound slide
travel.
130 mm 130 mm 135 mm 135 mm
Tall stock sleeve
travel.
130 mm 130 mm 130 mm 130 mm
Tool shank size.
16×16 mm 16×16 mm 16×16 mm 16×16 mm
Motor HP/KW.
2 / 1.5 2 / 1.5 3 / 2.2 3 / 2.2
Motor RPM.
1440 1440 1440 1440
Rated Amp.
3.5 A 3.5 A 5 A 5 A
Class of insulation.
E E E E
Duty type.
S 1 S 1 S 1 S 1
Net weight. (Approx.)
950 Kg. 1100 Kg. 1250 Kg. 1350 Kg.
Gross weight.
(Approx.)
1000 Kg. 1150 Kg. 1400 Kg. 1550 Kg.
Floor space occupied.
(Approx.)
2350 x 1100
mm
2800 x 1100
mm
2800 x 1150
mm
3350x1150
mm
