PANTHER
MODEL PAGE NO.
1350 / 1650 5
SR. SECTION DESCRIPTION PAGE
4.4 Surface slides and compound slide. 41
4.5 Tail stock. 41
4.5.1 Tail stock clamping. 41
4.5.2 Tail stock off set. 41
4.6 Tool post. 41
4.7 42
4.7.1 Machine vibrates during running. 42
4.7.2 Machine vibrates during machining. 42
4.7.3 Spindle running tight. 43
4.7.4 Machine cuts taper. 43
4.7.5
Gear train in end feed mech. makes
noise .
43
4.7.6 Machine not able to take heavy cuts 43
4.7.7 Noise in headstock. 44
4.7.8 Noise in main motor. 44
4.7.9 Lead screw does not rotate. 44
4.7.10 Main motor does not start. 44
4.7.11 Main motor does not start. 44
4.7.12 Threading over laps. 44
5
Assembly
drawings and
part list.
5.1 Head stock assembly. 46
5.2
Feed box assembly.
54
5.3 Carriage and tool post assembly. 64
5.4 Apron assembly. 68
5.5 Tail stock assembly. 74
5.6 Follow / Steady rest assembly. 77
5.7
Taper turning / rear tool post
assembly.
80
5.8 Switch shaft assembly. 84
5.9 Structure assembly. 88
