4.4 Surface Slide and Compound Slide.
In surface slide and compound slide setting wedge is given which
can be set by using setting screw.
4.5 Tail stock.
4.5.1 Tail stock clamping
Tail stock body is clamped on bed by eccentric lever (46).
Eccentricity of lever is fixed but length of clamping stud can be set by
hex nut provided on bottom side of clamping cast iron plate.
4.5.2 Tail stock – off set
Taper turning of long job can be done by off setting of tail stock
with respect to head stock centre line. In tailstock body two setting
bolts are provided on either side. By loosening one setting bolt and
tightening another setting bolt tail stock body can be set off set.
4.6 Tool post
After a long use the tool post clamping handle may extend beyond
the convenient zone of clamping. To get back proper angle of tool post
clamping handle face the bottom spacer of clamping lever by required
amount.
PANTHER
MODEL PAGE NO.
1350/1650 41
