PAR EverServ 600 - Main I;O Board and Ports; Additional I;O Ports; Service and Support Information; Safety Precautions

Service & support


Page 6
1
2
3
4
5
6
8
10
7 9
11
1
Cash Drawer
2
USB 2.0
COM Ports 2x20 Display Power Connector LAN MSR, Biometric
Main i/o Board
Additional i/o
1 2
1
SSD
LAN
2
COM1 (DB9)
3
COM 2 (RJ45)
4
COM 3 (RJ45)
5
2x20 Display
Only
6
Power Input
7
8
USB 2.0
9
VGA
10
MSR
11
Audio
