ParaBody 843 - Page 6

6
FIGURE 2
STEP 2:
• SECURELY assemble the six SPRING PIN ASSEMBLIES (12) to the SPRING PIN BARRELS on each SAFETY RAIL (3) and
each BAR SUPPORT (4) as shown in FIGURE 2.
0
1
2
345
6
1/2 1/2 1/2 1/2 1/2 1/2
• Insert twelve 3 X 2” INSERT GUIDES (15) into the ends of each SAFETY RAIL (3) and BAR SUPPORT (4) as shown in FIGURE
2. (NOTE: Make sure the INSERT GUIDES (15) snap into the holes of the weldments.)
4
12
3
15
15
12
