ParaBody 843 - Page 7

7
FIGURE 3
STEP 3
• Slide one BAR SUPPORT (4) and one SAFETY RAIL (3) (IN THAT ORDER) onto each UPRIGHT (1). Pull back on the
SPRING PIN ASSEMBLIES until they pop into holes.
• Insert four 2” SQ. END CAPS (13) into the ends of the UPRIGHTS (1) as shown in FIGURE 3.
3
4
1
13
