ParaBody 874 - Parts List

5
PARTS LIST
PART #
6650609
6650109
6649309
6624210
6624310
6259109
7710409
6654521
6654421
6406401
6412001
6236701
6692601
6405201
7234801
6145801
KEY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
QTY
1
1
1
1
1
1
1
1
1
2
1
1
1
1
4
1
PART #
3235204
3235212
3114403
3114702
3235315
3235322
3235432
3235501
3221705
6417801
6650201
6416601
7339801
7656301
3235207
DESCRIPTION
3/8 X 1” BOLT
3/8 X 3” BOLT
3/8” WASHER
3/8” LOCK NUT
1/2 X 3-3/4” BOLT
1/2 X 5-1/2” BOLT
1/2 X 8” BOLT
1/2” LOW HEIGHT LOCK NUT
1/2” E-RING
1/2 X 1” SPRING
1/2” FLANGE SPACER
1-1/2 X 3/4” GLIDE (8 PER)
1/2” DIA U-PIN
WHEEL
3/8 X 1-3/4” BOLT
QTY
6
4
14
6
1
1
1
3
1
1
2
1
1
2
2
DESCRIPTION
BENCH FRAME
ADJUSTABLE SLIDE
ADJUSTABLE SLEEVE
LEFT BACK PAD ANGLE
RIGHT BACK PAD ANGLE
FRONT BASE
REAR BASE
SEAT PAD
BACK PAD
HINGE TAB
SPRING PIN ASSEMBLY
1-3/4” SQ. END CAP
3 X 2” END CAP
2” SQ. END CAP
2” SQ. COVER CAP
THUMBSCREW
KEY
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
FIGURE 1
STEP 1:
• Assemble the 1/2” DIA. U-PIN (29) to the BENCH FRAME (1) using one 1/2 X 1” SPRING (26), and one 1/2” E-RING (25) as
shown in FIGURE 1.
1
16
29
25
26
• Thread one THUMBSCREW (16) into the BENCH FRAME (1) as shown in FIGURE 1. The THUMBSCREW (16) will be used to
tighten down attachments.
