ParaBody 887 - Parts List

4
PARTS LIST
PART #
LEA6800209
LEA6800610
LEA6800809
LEA6801009
LEA6801110
LEA6759810
LEA6274410
LEA6725310
LEA3116201
LEA3116101
LEA6802101
LEA6671601
LEA6692601
LEA3103102
LEA6140701
LEA6405201
LEA3116001
LEA6177001
LEA3119301
KEY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
QTY
1
1
1
1
1
1
1
1
5
1
1
1
2
4
8
2
1
2
2
PART #
LEA6236701
LEA6412001
LEA3203301
LEA6542402
LEA6416601
LEA3235314
LEA3114401
LEA3114701
LEA3235316
LEA3235502
LEA3114403
LEA3114702
LEA3235211
LEA6480301
LEA3103801
LEA3235208
LEA3108102
LEA6075906
LEA3235216
DESCRIPTION
1-3/4” SQ. END CAP
SPRING PIN ASSEMBLY
VINYL CAP
3/16 X 1-3/4 X 5-1/4” PLATE
3/4 X 1-1/2” GLIDE
1/2 X 3-1/2” BOLT
1/2” WASHER
1/2” LOCK NUT
1/2 X 4” BOLT
3/8” LOW HEIGHT LOCK NUT
3/8” WASHER
3/8” LOCK NUT
3/8 X 2-3/4” BOLT
3/8” FLANGE SPACER
5/16” SNAP HOOK
3/8 X 2” BOLT
1/4” QUICK LINK
12 LINK CHAIN
3/8 X 4” BOLT
QTY
1
1
2
2
1
1
2
1
1
3
14
9
6
8
3
2
1
1
4
DESCRIPTION
UPRIGHT
ADJ FOOT SUPPORT
PULLEY HOUSING
TOP BOOM
LAT BAR SUPPORT
CARRIAGE
LOW ROW BAR
LAT BAR
3-1/2” PULLEY
4-1/2” PULLEY
115-1/4” CABLE
121-3/4” CABLE
3 X 2” END CAP
1 X 8” GRIP
1 X 1” GLIDE
2” SQ. END CAP
1-1/4” SQ. RUBBER BUMPER
2-1/2 X 5-1/2” NON-SKID STRIP
2-1/2” ROUND END CAP
KEY
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
FIGURE 1
STEP 1:
• Remove four 7/16” CAP PLUGS from the UPPER & LOWER CROSS SUPPORTS on the 888 SMITH MACHINE as shown in FIGURE 1.
7/16” CAP PLUG
7/16” CAP
PLUG
