Esprit E55 / E65 23
Programmable Output Options
NOTE: PGM 1 (E55/E65) PGMs 2 and 3 (E65 only)
PGMs 6 to 8 are only available when using an ZX8 or ZX8SP Hardwired Zone Expansion module.
PGMs 9 to 12 are only available when using a PGM4 4-PGM Expansion module.
PGM cannot exceed 150mA (current limit).
49 to 56 = N/A
58 = Zone forced 01 to 32 = Zone number
99 = Any zone number59 = Zone included
64 = System Status 00 = Follow Arm LED status*:
1. PGM pulse fast in alarm
2. PGM pulse fast in exit delay below 10 sec.
3. PGM pulse slow in exit delay over 10 sec.
4. PGM steady ON if armed
5. PGM OFF if disarmed
* On-board PGM only: This event can be assigned to any partition. If
assigned to both partitions, the PGM event will follow the priority of
the list above, with #1 being the highest priority.
PGM 1
[261]
PGM 2
[262]
PGM 3
[263]
PGM 4-5
[264]-[265]
Option OFF ON OFF ON OFF ON
future use
[1]
PGM Base Time
Off=Sec, On=Min
N N N
[2] PGM State Off=N.O., On=N.C.
N N N
[3] N/A N/A N/A N/A N/A N/A N/A
[4]
PGM Activation Mode
Off=Steady, On=Pulse
N N N
[5]*
PGM Pulse once every 30
seconds if armed*
N N N
[6]* PGM Pulse on any alarm*
N N N
[7]
PGM Pulse on any alarm -
Off= Partition 1, On= Partition 2
N N N
[8]
Voltage Output (E65 PGMs only)
Off= Negative Trigger (0V)
On= Positive Trigger (12V)
N N N
ZX8 +1 ZX8 +9 ZX8 +17 PGM4
PGM 6
[266]
PGM 7
[267]
PGM 8
[268]
PGM 9
[269]
PGM 10
[270]
PGM 11
[271]
PGM 12
[272]
Option OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
[1]
PGM Base Time
Off=Sec, On=Min
N N N N N N N
[2] PGM State Off=N.O., On=N.C.
N N N N N N N
[3] N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
[4]
PGM Activation Mode
Off=Steady, On=Pulse
N N N N N N N
[5]*
PGM Pulse once every 30
seconds if armed*
N N N N N N N
[6]* PGM Pulse on any alarm*
N N N N N N N
[7]
PGM Pulse on any alarm -
Off= Partition 1, On= Partition 2
N N N N N N N
[8] N/A --------------
* If options 5 or 6 are enabled, The following Programmable Output Activation/Deactivation Events do not apply: [220], [230], [232], and [234].
Event Group # Sub-group #
