10.1 Programmable Outputs (PGMs)
Your system includes Programmable Outputs (PGMs) that can be programmed by your installer. A PGM triggers
when a predetermined event or series of events occurs in your system. The PGMs can be programmed to reset
smoke alarms, turn on light switches, open or close garage doors and much more. Ask your installer about this
useful feature.
10.2 Keypad Settings
You can modify the keypad settings to suit your needs.
1. Scrolling Speed refers to the amount of time that a message will remain on the screen before moving to the
next message.
2. Backlight refers to the illumination behind the buttons and LCD screen.
3. Contrast refers to how dark or pale characters will appear on the screen.
Figure 6 – Modifying LCD screen settings on LCD Keypads
10.3 Setting Time & Date
To reset the time and date:
1. Enter your [ACCESS CODE] and press the [TRBL] button.
2. Press the [
8] button.
Press [6]
Press [1]
Scrolling speed:
Choose a number from
0 to 10 (10 is the
slowest)
Press [2]
Backlight:
Choose a number
from 0 to 7 (7 is the
brightest)
Press [3]
Contrast:Choose a
number from 0 to 4
(4 has the most
contrast)
Press [4]
Mute: controls the keypad
beep †
Press [ACC] to enable/
disable ‡
Press [5] ‡
Dim intensity:
Choose a number from 0 to 7
(0 will dim the most after the
delay)
Press [6] ‡
Dim Delay: The delay
will dim after a delay
between 0 (no dimming)
and 255 seconds
[ ] and [ ]
To increase or decrease the numbers
Press [ENTER]
Press [CLEAR] to exit
Press [ ]to move to the next setting
Enter your [ACCESS CODE]
*This feature cannot be accessed via One-Touch Buttons (see
section 5.6.2
).
†
When keypad mute is enabled, only confirmation, rejection, and key-press beeps are audible.
‡
EVO641 / EVO641R only
To Next Page
