(800) 471-8769
19
Copyright 2021 © Paragon Tank Truck Equipment
#
P/N
Description
Qty
1
601-012
P657 Blower, with 3 Qts of Oil
1
2
508-107
HA Blower Bracket - P657 (Straight)
1
2
508-113
HA Blower Bracket - P657 Drivers Side
1
2
508-114
HA Blower Bracket - P657 Pass. Side
1
3
560-044
P657 Drive Flange 1310 Series (not shown)
1
4
625-006
Air Filter Assy S/S - P657 PSI Only 5” Side
outlet
1
4
625-002
Air Filter Assy S/S - P657 PSI/Vac 5” Side outlet
1
4
625-026
Air Filter Assy S/S - P657 PSI/Vac 5” Side outle,
with Vaccuum Gauge
1
5
587-000
Hose, Hump 5” X 4”
1
6
588-010
Tube, 4” od X 24” long
1
7
587-018
Hose, Hump 4”
1
8
526-036
Gasket, Delivery, Suction - P657
1
9
509-032
Flange, Suction Alum - P657 HA
1
10
291-012
Hose Clamp 4” - 6”
1
#
P/N
Description
Qty
11
291-002
Hose Clamp 3” - 5”
3
12
228-052
Capscrew - Hex Head
4
13
296-022
Flat Washer
4
14
294-009
Lock Washer
4
15
284-009
Nyloc Hex Nut
4
16
623-022
Air Filter Mounting Kit
1
17
563-000
Muffler, 4” MNPT X 4” FNPTSteel
1
17
563-007
Muffler, 4” MNPT X 4” FNPT Steel w Temp.
Gauge (not for food grade or sensitive
products)
1
17
563-001
Muffler, 4” MNPT X 4” FNPT Stainless Steel
1
17
563-002
Muffler, 4” MNPT X 4” FNPT Stainless Steel w
Temp. Gauge
1
18
533-005
Elbow, 2” Street - Galvanized
1
19
610-012
Relief Valve, 2” NMPT - 16 psi
1
19
610-013
Relief Valve, 2” NMPT - 18 psi
1
Horizontal Airflow (HA)
Diagram
