Paramina CYCLONE SILENT 24E - Page 52

User Manual - Cyclone Silent - 1-2018 edition
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 52
* Go to page 65 for service kit installation instructions.
Item
Qty
Part Nr.
Description
3.1
1
181091391
Analogue pressure sensor 3
rd
stage
3.2
1
219000022
Safety valve 3rd - 100bar series @70bar
3.3
1
208501620
Condensate separator 3
rd
stage (drawing at page 67)
3.4
1
208704200
4
th
stage water separator, max. 420 bar
1
127121422
O-ring 4
th
stage water separator
1
142101199
Sintered Filter
3.5
1
145063102
Oil drain valve
3.6
1
190000060
Oil level sensor
1
190000092
Oil level sensor service kit
3.7
1
219004552
Safety valve 4
th
stage (270b series) *
1
219004522
Safety valve 4
th
stage (420b series) *
3.8
1
116000212
Oil Filling Plug
3.9
1
151000090
Compressed Air Outlet ¼’’ BSP
1
115000832
1/4'' BSPP male / straight M16x1,5 8S male for
Stainless Steel pipe connection (Option)
1
153000122
Fitting connector male 16 x 1,5 - male 1/4'' for
Kevlar filling hose connection (Option)
3.10
1
151000090
Compressed Air Outlet ¼’’ BSP
1
115000832
Inlet to Dryer (Option)
3.11
1
151000090
Compressed Air Outlet ¼’’ BSP
1
115000832
Outlet to Dryer (Option)
3.12
1
205300160
By pass pipe set when dryer are not connected
