45
3
192081212
Copper Washer Ø8
46
3
511131004
Hex Head Screw M8x25
47
2
521151006
Top Cylinder Gasket
48
8
511123005
Washer Ø12
49
8
511131009
Hex Head Screw M12x80
50
4
193208252
Allen Screw M8x25
51
1
190027702
Flange Connection
52
4
193112252
Allen Screw M12x25
53
2
190001312
Flange Gasket
54
1
183700010
Flange
55
1
190000472
Cylinder 3
rd
Stage
56
4
194200802
Hex Nut M8
57
1
133030022
Piston Ring Set 3
rd
Stage
58
1
141003002
3
rd
Stage Piston
59
1
183000142
Gasket Cylinder Guide 4
th
stage
60
1
190000482
Cylinder Guide 4
th
Stage
61
4
193108302
Allen Screw M8x30
62*
1
*
Piston Rings Set 4
th
Stage
63*
1
*
Piston 4
th
Stage
64*
1
*
Piston Sleeve 4
th
Stage
65*
1
127057122*
O-Ring Piston Sleeve 4
th
Stage
66
2
192000122
Copper Washer
67
1
154000430
Inlet Valve 3
rd
Stage
68
1
127056412
O-Ring Discharge Valve 3
rd
Stage
69
1
154000450
Discharge Valve 3
rd
Stage
70
1
190000522
Valve Head 3rd Stage
71
6
193108352
Allen Screw M8x35
72
1
154000200
Inlet Valve 4
th
Stage
73
1
127054362
O-Ring Discharge Valve 4
th
Stage
74
1
154000280
Discharge Valve 4
th
Stage
75
1
190000292
Valve Head 4
th
Stage
76
1
190000602
Top Cover 4
th
Stage
77
6
193108982
Allen Screw M8x120
78
1
193087002
Set Screw
79
1
192081212
Copper Washer Ø8
80
1
194000802
Plug Allen Screw
81
1
116000142
Plug ¼’’ + O-Ring
82
2
521157001
Side Cover Gasket – crankcase
83
1
521114001
Crankcase Side Cover Right
84
12
511131004
Hex Head Screw M8x25
85
1
521114002
Crankcase Side Cover Left
86
1
521165001
Oil Sight Glass
87
2
521157007
Gasket – side cylinder 1
st
& 2
nd
stage
88
2
183700000
Flange
89
6
193112252
Allen Screw M12x25
90
1
521157009
Gasket – side cylinder head 1
st
& 2
nd
91
1
183700020
Flange
92
1
521136002
Flat Key – Wedge Crankshaft
