Paramina Typhoon Open 13E User Manual

User Manual - Typhoon Open – 01/2018 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 57
Item
Qty
Part Nr.
Description
1
1
211130051
Bearing Seat
2
1
126355092
Oil Seal
3
1
211310071
Crankshaft
4
1
110063072
Crankshaft’s Ball Bearing 1
5
1
110063042
Crankshaft’s Ball Bearing 2
6
1
211110211
Crankcase
7
1
211520051
Bearing Seat Gasket
8
2
211320071
Side Con Rod 2
nd
& 3
rd
Stage
9
1
211320081
Center Con Rod 1
st
Stage
10
1
211460031
Flat Crankshaft Circlip d30
11
1
211460041
Crankshaft’s Circlip d30
12
10
192200802
Washer Ø8
13
14
198000802
Lock washer Ø8
14
6
197008252
Hex Head Screw M8x25
15
1
211550011
Bearing Cover Gasket
16
1
211120031
Bearing Cover Triangle
17
3
192200602
Washer Ø6
18
3
198000602
Lock Washer Ø6
19
3
197006202
Hex Head Screw M6X20
20
12
211410031
Crankcase Screw M10
21
2
141600202
Piston Crosshead 2
nd
& 3
rd
Stage
22
2
211430031
Piston Pin 2
nd
& 3
rd
Stage
23
6
211440031
Piston Pin Lock
24
3
211530031
Crankcase Cylinder Gasket
25
2
211210071
Cylinder 2
nd
& 3
rd
Stage
26
9
192201002
Washer Ø10
27
12
198001002
Lock Washer Ø10
28
12
194201002
Hex Nut M10
29
1
211410041
Piston 1
st
Stage
30
1
211450041
Piston Rings Set 1
st
Stage
31
1
211430041
Piston Pin 1
st
Stage
32
3
106050090
Flat Chisel Intercooler-Aftercooler Support
( +1 for Petrol & Diesel)
33
1
211210051
Cylinder 1
st
Stage
34
1
183603002
Gasket 2
nd
Stage Cylinder Guide
35
1
190713202
Cylinder Guide 2
nd
Stage
36
4
197008202
Hex Head Screw M8x20
37
1
141365370
Piston 2
nd
Stage (has replaced p.n. 141365372 from
compressors serial number 1715785 & 1718416)
38
1
133365360
Piston Rings Set 2
nd
Stage (has replaced p.n. 133365361
from compressors serial number 1715785 & 1718416)
39
1
183602002
Gasket 3
rd
Stage Cylinder Guide
40
1
190000492
Cylinder Guide 3
rd
Stage
41
4
193108252
Allen Screw M8X25
42
1
*
Piston Sleeve 3
rd
Stage
43
1
*
Piston 3
rd
Stage (replaced 141001402)
44
1
*
Piston Rings Set 3
rd
Stage (replaced 133001401)
45
1
127057122*
O-Ring Piston Sleeve 3
rd
Stage
