Paramina Typhoon Open 13E User Manual

User Manual - Typhoon Open – 01/2018 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 58
46
1
154000440
Discharge Valve 2
nd
Stage
47
1
127056412
O-Ring Discharge Valve 2
nd
Stage
48
1
154000430
Inlet Valve 2
nd
Stage
49
2
192000122
Copper Washer 2
nd
Stage Valves Head
50
1
190000512
Valve Head 2
nd
Stage
51
6
193108352
Allen Screw M8x35
52
1
154000200
Inlet Valve 3
rd
Stage
53
1
154000280
Discharge Valve 3
rd
Stage
54
1
127054362
O-Ring Discharge Valve 3
rd
Stage
55
1
190000272
Valve Head 3
rd
Stage
56
1
190000282
Top Cover 3
rd
Stage
57
6
193108902
Allen Screw M8x90
58
1
211510051
Bottom Gasket Reed Valve
59
1
211240041
Reed Valve 1
st
Stage
60
1
211540031
Top Gasket Reed Valve
61
1
211230041
Cylinder Head Aluminum 1
st
Stage
62
4
197008752
Allen Screw M8x75
63
1
193084002
Set Screw
64
1
192081212
Copper Washer Ø8
65
1
194000802
Plug (Allen screw)
66
1
211670021
Oil Filling Plug
67
1
211640041
Oil Sight glass
68
1
190500610
Safety Valve 1st Stage (7 bar)
69
1
211360011
Half Circlekey (DIAM 5 X 19)
70
1
211121012
Washer (F10-52-5)
71
1
192201002
Washer Ø10
72
1
211131011
Pulley Bolt
73
1
136368001
Flywheel
* Supply / Order only as assembly – 3
rd
stage piston complete = 141000021 (replaced
141000020)
