English
5/8
ICE310-360
4.4.1.2 Alarm relay management
0
Relay normally deactivated, excited by an alarm.
1
Relay normally excited (also with control OFF), deactivated
by an alarm.
2
Relay normally excited (only with control ON), deactivated
by an alarm or with control OFF.
4.4.2 Temperature control
PARAMETER CODE TYPE DEFAULT
Temperature control set point
SEt
D
--
Temperature control differential
dIF
D
4.0
Set point lower limit
LI5
U
5.0
4.4.3 B1 sensor parameters
PARAMETER CODE TYPE DEFAULT
High temperature con guration
cHAI
U
0
High temperature alarm
HAI
D
60.0
Low temperature alarm
LAI
D
-20.0
Sensor calibration
CAI
U
0.0
Low temperature alarm reset
differential
dbI
U
1.0
4.4.4 B2 sensor parameters
PARAMETER CODE TYPE DEFAULT
High temperature con guration
cHA2
U
0
High temperature alarm
HA2
U
60.0
Low temperature alarm
LA2
U
3.0
Sensor calibration
CA2
U
0.0
B2 sensor presence
Ab2
U
1.0
4.4.5 P1 sensors parameters
Transducer calibration
CAP1
U
00
4.4.6 P2 sensors parameters
Transducer calibration
CAP2
U
00
4.4.7 Compressor parameters
PARAMETER CODE TYPE DEFAULT
Compressor rotation
rot
U
2
Compressor 1 enabling
AbC1
U
0
Compressor 3 enabling
AbC3
U
0
Compressor 2 enabling
AbC2
U
0
Compressor 4 enabling
AbC4
U
0
Compressor 1 operation hour
counter
HI
D
-
Compressor 3 operation hour
counter
H3
D
-
Compressor 2 operation hour
counter
H2
D
-
Compressor 4 operation hour
counter
H4
D
-
Compressor 1 hour counter
threshold
tHI
U
0
Compressor 3 hour counter
threshold
tH3
U
0
Compressor 2 hour counter
threshold
tH2
U
0
Compressor 4 hour counter
threshold
tH4
U
0
4.4.8 Pump parameters
PARAMETER CODE TYPE DEFAULT
Pump stop delay
dP5
U
5
Pump start delay
dPA
U
5
4.5 Parameter management
4.5.1 Temperature setting (see fi g.1)
1. 1. Turn the main swicth (QS) to “ON” and wait for the temperature
visualization.
2. Press buttons “P3” and “P5” together, to enter into “dIrE” (D)
parameters.
3. Press button “P4” to select “SEt” parameter, press the button
P5” to con rm.
4. Change the value, using the up and down arrow buttons “P3” and
P4”, then press button “P5” to con rm.
6. Press the button “P3” to return on “dIrE parameter.
7. Press the button “P5” to exit.
4.5.2 Differential setting (see fi g.1)
1. Turn the main swicth (QS) to “ON” and wait for the temperature
visualization.
2. Press buttons “P3” e “P5” together, to enter into “dIrE” (D)
parameters.
3. Press button two times “P4” to select “diF” parameter, press the
button “P5” to con rm.
4. Change the value, using the up and down arrow buttons “P3” and
P4”, then press button “P5” to con rm.
6. Press the button two times “P3” to return on “dIrE parameter.
7. Press the button “P5” to exit.
4.5.3 Visualization sensors B1,B2...
“B1” is the “set” sensor of the macchine.
1. Start the chiller.
2. Press the button “P4” to visualize the temperature of the next sen-
sor.
3. Press the button “P5” to visualize the sensors “b01” ..“b02”....
It is recommended to leave on the display the B1 “set” sensor.
