TWP/TWB200 – TWP/TWB9000
50
MODBUS REGISTER MAP (CONT’D)
40038 R/W Calibration - System Display Pressure Units 0 = psi, 1 = kPa, 2 = bars, Does not affect Modbus register units.
40039 R/W Calibration - User Sensor #1 Units 0 = none, 1 = %, 2 = ow (scfm), 3 = ow (metric), 4 = pressure
(sys units), 5 = temp. (sys units), 6 = power (W), 7 = Current
(Amps /10 ), 8 = Volts
40040 R/W Calibration - User Sensor #2 Units 0 = none, 1 = %, 2 = ow (scfm), 3 = ow (metric), 4 = pressure
(sys units), 5 = temp. (sys units), 6 = power (W), 7 = Current
(Amps /10 ), 8 = Volts
40041 R/W Control Set - Heated - Drying Time Factory Setting, dryer tower drying time,
Default is 240 minutes per tower
40042 R/W Control Set - Heated - Heat Purge Time Factory Setting, Regeneration heating time,
Default is 150 minutes
40043 R/W Control Set - Heated - Cooling Purge Time Factory Setting, Regeneration total cooling time,
Default is 87 minutes
40044 R/W Control Set - Heated - Blower Cool-down Time Factory Setting, Time for cooling down heater tube. Default is 2
minutes, Blower models only
40045 R/W Control Set - Heated - Ambient Cooling Time Factory Setting, Ambient cooling time. Default is 25 minutes,
(Blower models only)
40046 R/W Control Set - Heated - Extended Dry Purging Time Factory Setting, Maximum extended cooling time.
Default is 60 minutes, (Blower models only)
40047 R/W Control Set - Heated - Repressurization Time Factory Setting, Repressurization Time, default is 180 seconds
40048 R/W Control Set - Tank Blowdown Time Factory Setting, Tower blowdown time, default is 120 seconds.
40049 R/W Control Set - Heatless - Drying Time Factory Setting, Heatless Drying Time. Default is 420 seconds
40050 R/W Control Set - Heatless - Repressurization Time Factory Setting, Heatless Repressurization Time,
Default is 60 seconds.
40051 R/W Control Set - Inlet Swing Time Factory Setting, Time allocated for controlling inlet valves,
Default is 2 seconds.
40052 R/W Control Set - Heating Exhaust Limit Exhaust Limit setting from 100°F to 250°F, Default is 150°F
40053 R/W Control Set - Cooling Exhaust Limit Exhaust Limit setting from 0°F to 150°F, Default is 150°F
40054 R/W Control Set - Purge Temperature Purge temperature from 0°F to 600°F, Default is 400°F
40055 R/W Control Set - Instrument Air Pressure Control air pressure from 10 to 200 psi, Default is 60 psi
40056 R/W Control Set - Variable Cycle Dewpoint Threshold Dewpoint demand setting, Default is -40°F
40057 R/W Control Set - Number of Heater Banks Factory Setting, Number of heater banks to control from 1 to 4
40058 R/W Control Set - Drain 1 Interval in seconds Drain interval time from 10 to 3600 seconds,
Default is 600 seconds (10 minutes)
40059 R/W Control Set - Drain 1 Duration Minimum amount of time to open drain.
Default is 10 seconds
40060 R/W Control Set - Drain 1 Auto test in minutes Automatically re demand drain every 720 minutes,
Settable from 30 to 1440
40061 R/W Control Set - Drain 2 Interval in seconds Drain interval time from 10 to 3600 seconds,
Default is 600 seconds (10 minutes)
40062 R/W Control Set - Drain 2 Duration Minimum amount of time to open drain,
Default is 10 seconds
40063 R/W Control Set - Drain 2 Auto test in minutes Automatically re demand drain every 720 minutes,
Settable from 30 to 1440
40064 R/W Control Set - Drain 1 Type 0 = disabled, 1 = Use drain cycle time, 2 = Use demand switch
40065 R/W Control Set - Drain 2 Type 0 = disabled, 1 = Use drain cycle time, 2 = Use demand switch
40066 R/W Control Set - Model Type 0 = not set, 1 = Externally Heated, 2 = Blower Purge
40067 R/W Control Setting - Start Dryer in Heated Mode 1 = switch from heatless to heated mode
40068 R/W Control Setting - Start Dryer in Heatless Mode 1 = switch from heated to heatless mode
