Parker DA - Model DA Parts List

Media Bag Dust/Mist Collector Models DA, DB, DBM
14
Model DA - Final Assembly
Item No. Part No. Description Quantity
1 32-0155 BLOWER 1
2 (Select one) 02-2609 MOTOR (115V) 1
22-0180 MOTOR (208-230V)
3 23-0016 MOTOR MOUNT BRACKET 1
4 32-0039 RUBBER GROMMET (BLOWER MOUNT) 4
5 30-0077 SCREW BLOWER MOUNT 4
6 32-0039 RUBBER GROMMET (BLOWER MOUNT) 3
7 32-0154 SLEEVE FOR MOTOR MOUNT GROMMET 3
8 20-2640 CAPACITATOR (MOTOR) 1
9 33-0021 OUTLET GRILLE 1
10 33-0031 SCREW FOR GRILLE 6
11 42-0176 GASKET (INLET FLANGE) 8 ft.
12 02-2996 POWER CORD 1.
13 39-0120 KNOB - UNIT CONTROL 1
14 20-1414 UNIT CONTROL SWITCH 1
15 07-0081 PRESSURE GAUGE, 0-5” STATIC PRESSURE 1
16 20-1280 FLEX TUBING FOR GAUGE .5 ft.
17 41-1108 LABEL, GAUGE/CONTROL SWITCH 1
18 35-0143 FILTER CUP 2
10. Parts Lists
