Parker DA - Model DB Parts List

Media Bag Dust/Mist Collector Models DA, DB, DBM
16
Model DB - Final Assembly
Item No. Part No. Description Quantity
1 32-0153 BLOWER 1
2 (Select one) 22-0159 MOTOR 2HP (115-230/1/60) 1
22-0039 MOTOR 2HP (208-460/3/60)
22-0055 MOTOR 2HP(575/3/60)
22-0171 MOTOR 3HP (208-460/3/60)
22-0172 MOTOR 3HP (575/3/60)
3 CALL FACTORY PULLEY SET 1
4 32-0013 RUBBER GROMMET (BLOWER MOUNT) 4
5 30-0058 BOLT BLOWER MOUNT 4
6 10-2689 MOTOR SUPPORT BRACKET 1
7 10-2688 MOTOR BRACKET (TENSION PLATE)
8 33-0026 OUTLET GRILLE
9 30-0031 SCREW FOR GRILLE 6
10 42-0206 GASKET (OUTLET) 8 ft.
11 07-0081 PRESSURE GAUGE, 0-5” STATIC PRESSURE 1
12 20-1280 FLEX TUBING FOR GAUGE .05 ft.
13 39-0071 T-HANDLE DOOR LATCH 2
14 42-0206 GASKET (1” x 1”) 4
15 42-0058 GASKET - DOOR EDGE 4 pcs/door
