2. Description of Components
The Dust/Media Collector is available in a front-load (Model DA) and two-side-load (Model DB and
Model DBM) congurations.
Your air cleaner is supplied with prelter and primary lter sections selected to suit your application.
The prelter section traps most of the larger particles and some of the smaller ones, allowing the primary
lter section to operate at its higher efciency over periods of time.
The following describe each of the lter options.
Prefilter
Type
Description Part No.
Availability Efficiency
(ASHRAE
52.1-92)
Depth
of
Filter
Weight
(lbs/kg)
DA DB DBM
Extended
Surface Bag
• Ultra-fine fiberglass media
• Galvanized steel
header frame
33-1210 • • 65% 22”
8/
3.6
33-1207 • 65% 29”
33-0131 • • 65% 36”
33-1211 • • 95% 22”
33-1208 • 95% 29”
33-0133 • • 95% 36”
33-1212* • • 95% 22”
33-1209* • 95% 29”
33-0142* • 95% 36”
Carbon Cell
• (12)-1” trays of carbon|
(45 lbs.)
• Metal frame
• Refillable
• Replacement filter trays
(12)
33-0143 • 95% 12”
125/
56.7
33-0141 N/A 12”
HEPA
• Waterproof glass media
• Particle board frame
33-0144 • 99.97%** 12” 32/14.4
33-1218 • 99.97%** 6” 20/9.
Prefilter
Type
Description Part No.
Availability Efficiency
(ASHRAE
52.1-92)
Weight
(lbs/kg)
DA DB DBM
Extended
Surface Bag
• Synthetic fiber
• Steel frame attaches to cabinet
33-0129 • • •
92% Dust
arrestance
1.5/70
4” Pleated
• Pleated non-woven reinforced
cotton fiber media
• Heavy-duty fiberboard frame
33-0130 • • •
95%
2.1/95
N/A
2’” Oil
Impinger
• Two layers of aluminum baffles
• Permanent impingement filter
33-0140 • • N/A 8/3.6
2” Aluminum
Mesh
• Expanded aluminum mesh
22-1206 • • N/A
2” Pleated
• Pleated non-woven reinforced
cotton fiber media
`33-1213 • •
35%
(ASHRAE
52.1-92)
Table 1 Pre-Filter Options
Table 2 Primary Filter Options
