12
,
7.4 Spare parts
PCW420-650
Component (7.4 / 7.5) PCW420 PCW510 PCW650
electronic control
21
On request
(CPT) On request
high pressure switch
23
398H354052
low pressure switch
24
398H354054
electrovalve
28
398H183105
Ambient temperature sensor (6m)
29
398H275235
Evaporator temperature sensor (6m)
30
398H275235
local display A2
ET-398H275943
main diconnector switch QS
398H256425
compressor automatic switch QF1-4
398H256290 398H256363
compressor contactor KM1-4
398H256353 398H256325 398H256362
fan contactor KM5
398H256243
pump contactor KM7
398H256245
high pressure alarm relay KA1/10
398h256152
antifreeze heater contactor KRA1
398H256243
plastic capillary -
398H370014
