PKHAP 20-Li A1
GB
│
CY
│
3 ■
Technical specifications
Cordless Hammer Drill 20V PKHAP 20-Li A1
Rated voltage 20 V (DC)
Idle speed n
0
0–950 rpm
Stroke rate 0–4700 rpm
Impact energy 3 J
Max. drill diameter 13 mm for steel
27 mm for wood
24 mm for concrete
Battery PAP 20 A3*
Type LITHIUM ION
Rated voltage 20 V
(DC)
Capacity 4 Ah (80Wh)
Cells 10
High-speed battery charger PLG 20 A3*
INPUT
Rated voltage 230–240 V
~
, 50 Hz
(AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT
Rated voltage 21.5 V
(DC)
Rated current 4.5 A
Charging time approx. 60 min
Protection class II / (double insulation)
* BATTERY AND CHARGER ARE NOT INCLUDED
ATTENTION! Hot surface.
There is a risk of burns.
Noise emission value
Noise measurement value determined in accord-
ance with EN 60745. The A-rated noise level of
the power tool is typically as follows
Hammer-drilling
Sound pressure level L
pA
= 93.6 dB (A)
Uncertainty K = 3 dB
Sound power level L
WA
= 104 dB (A)
Uncertainty K = 3 dB
Total vibration value
Total vibration values (vector total of three direc-
tions) determined in accordance with EN 60745:
Hammer-drilling (main handle)
a
h, AG
= 5.677 m/s
2
, K = 1.5 m/s
2
(additional handle)
a
h, AG
= 6.334 m/s
2
, K = 1.5 m/s
2
WARNING!
► The vibration level specified in these instruc-
tions has been measured in accordance
with the standardised measuring procedure
specified in EN 60745 and can be used to
make equipment comparisons. The specified
vibration emission value can also be used to
make an initial exposure estimate.
The vibration level varies depending on the
use of the power tool and may, in some
cases, be higher than the value specified in
these instructions.
