Overview
1 U-handle
3 Lower bar
4 Bowden cable
H
4a Locking nut
H
4b Adjusting nut
5 Impact protection
6 Handle
8 Lawn mower housing
9 Wheels
10 Impact protection on the side
ejection
11 Wing screw
12 Machine cable
C
C
13b Rod
C
13c Tabs
14 Filling level indicator
15 Quick-release lever with washer
18 Release button
19 Drive bracket
20 Bail bar
21 Side ejection chute
22 Mulching kit
B
24 Triangular grip screw
E
25 Ratchet mechanism
F
26 Handle
I
27 Blade
I
28 Blade bolt
I
29 Motor spindle
adults. It is not to be used by children or
people who are unfamiliar with these in-
structions. The use of the equipment is pro-
hibited in the rain or a damp environment.
The manufacturer will not be liable for
damages caused by use other than for the
intended purpose or by incorrect operation.
General Description
Scope of Delivery
packaging and check whether the follow-
ing parts are complete:
- Electric lawnmower and U-shaped
handle with appliance cable
- Lower bar
- Lawn bag
- Side ejection chute
- Mulching kit
- 2 quick-release levers with washers
and triangular grip screws
- 2 wing screws for fastening the bar/
lawn mower housing
- 3 cable holders
- Instruction Manual
Function Description
The electric lawnmower has a cutting tool,
which turns parallel to the cutting level.
It comes with a high-performance electric
motor, robust plastic housing, release
button, mulching kit, side grass ejection,
The machine can also be adjusted to 8
different height levels and features smooth-
running wheels.
For the function of the operating parts,
please refer to the descriptions below.
