PSBSAP 20-Li A1
GB
│
IE
│
NI
│
9 ■
Inserting/removing the battery pack
Inserting the battery pack
♦ Set the rotation direction switch to the middle
position (lock). Push the battery pack! into
the handle until it clicks into place.
Removing the battery pack
♦ Press the release button. and remove the
battery pack!.
Checking the battery charge level
♦ Press the battery charge level button1 to
check the status of the battery (see the main
diagram). The status/remaining charge will be
shown on the battery display LED6 as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Additional handle
NOTE
►
For safety reasons, you should never use
this tool without the additional handle
attached.
♦ Loosen the strap on the additional handle
by turning it clockwise.
♦ Slide the mounting ring for the additional
handle over the chuck3.
♦ Turn the additional handle to the required
position.
♦ Afterwards, twist the additional handle
anticlockwise again to tighten it.
Depth stop
♦ Push the locking button for the depth stop
and keep it pushed in.
♦ Fit the depth stop into the additional
handle.
♦ Make sure that the teeth on the depth stop
point upwards and downwards.
♦ Pull the depth stop out until the distance
between the tip of the drill and the tip of the
depth stop corresponds with the required
drilling depth.
♦ Release the locking button for the depth stop
to lock the depth stop in place.
Changing tools
Your cordless impact drill driver has a fully auto-
matic spindle lock
.
When the motor is stopped, the power train is
locked so that the chuck3 can be opened by
turning
. After you have attached the desired
tool and tightened it by turning the chuck , you
can continue working. The spindle lock is released
automatically when the motor is started (by pressing
the ON/OFF switch).
Torque selection/selecting the
operating mode
You can set the torque using the torque selection
ring- or by choosing between the drill setting
and the hammer drill setting
.
♦ Select a low level for small screws or soft
materials.
♦ Select a high level for large screws, hard
materials or removing screws.
♦ Select the drill setting for drilling work by adjusting
the torque selection ring to the position
.
♦ Select the hammer drill setting for hammer drilling
work by adjusting the torque selection ring to
the position
.
IB_329697_PSBSAP20-LiA1_LB6.indb 9 26.08.20 17:08
