General description
The illustrations can be found
on the front and rear fold-out
pages.
Scope of delivery
Unpack the equipment and check that it is
complete. Dispose of the packaging mate-
rial correctly.
• Appliance
• 2 x spark protection
• mounting material for xing the spark
protection to the spark protection
holder
- 2 x holder for spark protection
- 2 xing screws, 2 spring washers,
2washers, 2 nuts
• mounting material for xing the spark
protection to the device
- 4 adjusting screws incl. washers and
spring washers, 4 nuts
• 2 workpiece supports
• mounting material for xing the work-
piece supports to the device
- 2 star washers, 2 screws, 2 washers,
2 toothed washers
• Instruction Manual
Function description
The double bench grinder is a combined
device tted with two grinding discs with
different grain size for coarse and ne
grinding.
The device is provided with a spark protec-
tion and protective hoods for the protection
of the user.
For the function of the operating parts,
please refer to the descriptions below.
Summary
1 Spark protection
2 Spark protection holder
3 Adjusting screw for spark protec-
tion
4 Fixing screw for spark protection
5 Protective hood grinding disc
6 Motor housing
7 Fixing screws for grinding disc
cover
8 Grinding disc cover
9 Power cable
10 Grinding disc
11 Workpiece support
12 Star grip nut to mount/adjust
the workpiece support
13 Drillholes for table mounting
14 On/off switch
14a On switch
14b Off switch
15 Grinder spindle
