Parkside 286097 - Technical Details

PMDS 100 B1
GB
│
IE
│
13 ■
Technical details
Rated voltage: 230–240 V∼, 50 Hz
(alternating current)
Rated power
consumption: 100 W S2:20min*
Protection class: II /
(double insulation)
Protection type: IP 20
Rated idle speed: n
0
3000–9000 rpm
Working speed: 8–24 m/s
n
0
3000–9000 rpm
V 8–24 m/s
Weight (incl. accessories): approx. 1.7Kg
* After uninterrupted operation for 20 minutes, you
must take a break until the appliance temperature
is within 2 K (2°C) of room temperature.
Grinding discs
D Ø max. 50 mm
d Ø 12.7 mm
t 13 mm
Outer diameter: Ø 50 mm
Drill hole: Ø 12.7 mm
Thickness: 13 mm
Hardness grade: M
Grain size: 100/80
Steel wire brush/brass wire brush
D Ø max. 50 mm
d Ø max. 10 mm
t max. 10 mm
Outer diameter: Ø 50 mm
Bore: Ø 5 mm
Thickness: 8.5 mm
■ Use only brushes with a max. hole diameter of
10 mm and max. brush thickness of 10 mm.
Noise emission value:
Noise measurement value determined in accord-
ance with EN ISO 4871. The rated noise level of
the tool is typically:
Sound pressure level: L
pA
= 60.94 dB (A)
Uncertainty: K
pA
= 3 dB
Sound power level: L
WA
= 73.94 dB (A)
Uncertainty: K
WA
= 3 dB
Wear hearing protection!
Total vibration value:
Total vibration value as per EN 61029:
Vibration emission value a
h
≤ 2.5 m/s
2
Uncertainty K
h
= 1.5 m/s
2
NOTE
► The vibration level specified in these instruc-
tions has been measured in accordance with
a standardised measuring procedure and can
be used to make equipment comparisons. The
specified vibration emission value can also
be used to make an initial exposure estimate.
