Caution! When using equipment, certain safety precautions
must be complied with in order to avoid injuries and damage.
You should therefore read these operating instructions / safety
-
mation is available to you at all times. Should you give the de-
vice to anyone else, please give them these operating instructions
/ safety instructions as well. We assume no liability for accidents
or damage caused by failure to observe these instructions or the
safety instructions. Changes to the machine will cause the ma-
nufacturer‘s liability with respect to any resulting damage to be
completely excluded. Even when the device is used in accordan-
ce with the designated purpose, it is nevertheless not possible to
completely eliminate certain residual risk factors. Due to the de-
sign and structure of the machine, the following risks may occur:
-
• Reaching into the running saw blade (cuts)
• Saw blade breaks.
• Ejection of faulty hard metal parts of the saw blade.
• Hearing damage if the necessary hearing protection is not used.
• Emissions of wood dust which are harmful to the health when
used in closed rooms.
-
gnated purpose does not include commercial, handicraft or industrial
applications. We assume no warranty if the device is used in commer-
cial, handicraft or industrial businesses or for equivalent purposes.
General description
Extent of the delivery
Carefully unpack the appliance and check that it is complete:
- Saw table with pre-assembled
carbide-tipped saw blade with 24 teeth
carbide-tipped saw blade with 48 teeth
(additionally enclosed)
- Blade guard
- Riving knife with laser
- Batteries 1.5V AAA (2x)
- Stop rail
- Legs (4x)
- Central struts (4x)
- Rubber feet (4x)
- Stand brackets (2x)
- Instruction for use
Mounting Material
- Bag A for base frame, centre struts and stand brackets:
(e) Nuts, 12 pieces
- Bag B for table length/width extension and collection bag:
(g) Carriage bolt, small with two nuts, 4 pieces
Tools
- (h) Hexagon socket wrench HX 6
- (k) Ring spanner AF 10/22
- (i) Open-ended spanner AF 8/10
Additional tools required
.
Overview
1
1 Saw table
2 Saw blade guard
3 Riving knife (not visible)
4 Saw blade (not visible)
8 Cam lever
9 Locking handle
10 Scale
11 Handwheel
12 Crank handle
13 Base frame
14 On/off switch
15 Collection bag for wood residues
16 Guide rail
2
18 Suction adapter
20 Bracket for saw blade storage
4
21 Legs (4x)
22 Central struts (4x)
23 Rubber feet (4x)
24 Stand brackets (2x)
5
25 Attachment points
10
16
28 Countersunk screws of the table insert
17
29 Fixing screws of the riving knife
18
30 Slot in the riving knife
