GB IE
8
NI
19
26
32 Cam lever
33 Groove
31
35 Laser
36 Laser switch
32
37 Screw for battery compartment
38 Battery cover
37
39 Stop rail
Functional description
-
hwise and crosswise (only with the transverse stop), depending
on the machine size. All types of round timbers must not be cut
with it.
Technical data
Bench circular saw.............................................................. PTK 2000 D3
AC motor ......................................................... 230 V~ 50Hz
...................................................................2000 Watt
Operating mode ...................................................... S6 40%*
Safety class ..................................................................... II
..........................................................
Idling speed ..........................................................4800 min
-1
Carbide saw blade ..............................ø 254 x ø 30 x 2.8 mm
Idling speed saw blade, n max. .............................. 7000 min
-1
Number of teeth ......................................................... 24 / 48
...................................................2.5 mm
min. Workpiece size WxLxH ............................... 10x50x1 mm
........................................................630 x 445 mm
...........................620 x 250 mm
................................. 435 x 320 mm
Cutting height max. 90° ................................................73 mm
Cutting height max. 45° ................................................63 mm
Height adjustment ...................................................0 - 73 mm
Saw blade, swivelling ...................................................0 - 45°
Extraction connection ................................................. ø 34 mm
Weight (including accessories),
..................................................................... approx 21.5 kg
Laser class ...........................................................................2
Laser wavelength ....................................................... 650 nm
Laser power ............................................................. < 1 mW
Laser module power supply
........................................................... 2 x 1.5 V Micro (AAA)
Sound pressure level
(L
pA
) ..................................................
pA
= 3 dB
Sound power level (L
WA
)
measured .........................................
WA
= 3 dB
guaranteed .........................................................108 dB(A)
* Operating mode S6 40%: Continuous operation with intermittent load
(cycle time 10 min). In order not to heat the motor more than permitted,
the motor may only be operated for 40% of the cycle time with the stated
nominal power and must then continue running for 60% of the cycle time
without a load.
of further development without notice. All dimensions, references
and information in this instruction manual are therefore not guar-
anteed. Legal claims made on the basis of the instruction manual
can therefore not be considered as valid.
Safety instructions
CAUTION!-
served while using electric tools to protect against electric shock,
this electric tool and keep the safety instructions in a safe place.
Symbols and icons
Symbols on the appliance:
Carefully read these Operating Instructions.
Wear eye protection.
Wear ear protection.
Wear breathing protection.
Caution - Risk of injury.
Never reach into the running blade.
wet, nor should it be operated in a moist environment.
Caution! - Laser radiation. Do not look into the beam.
Laser class 2
Information of the acoustic power level L
WA
in dB.
Safety class II (Double Isolated)
Electrical appliances must not be disposed of with the
domestic waste.
Graphical symbol additionally on the saw
blades
Caution - a damaged blade must not be used under any
circumstances. Replace the saw blade immediately.
29
