cial use. Commercial use will invalidate the
guarantee.
-
charged using chargers from the Parkside
General description
front and back fold-out page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Battery-operated hammer drill
- 1 x 10mm quick-release drill chuck
with SDS Plus adapter
- 2 x SDS Plus drill bit, 6 mm and 8 mm
- 2 x drill bit for wood, 3 mm and 5 mm
- 4 x 50mm screw bits: S2, PH2, PH1,
- Storage case
- Instruction Manual
Battery and charger are not included.
Overview
1 SDS Plus tool holder
2 Dust protection cap
3 Locking sleeve
4 Changeover switch “drilling/im-
pact drilling”
5 Changeover switch retaining
knob
6 Charge status indicator LED
7 Direction of rotation switch
8 On/off switch
9 Battery
10 Button for unlocking the battery
pack
11 LED working light
12 Case
13 Quick charger
14 Screw bits
15 Wood drill bits
16 Drill bits with SDS Plus receptor
17 Keyless chuck
Functional description
non-removable keyless chuck, a removable
3-jaw chuck, right-left rotation and an LED
working light. Read the sections below to
learn more about each operating element’s
function.
Technical data
Cordless Hammer Drill PBHA 12 A1
Motor voltage U ..........................
Idling speed n
0
......................0-900 min
-1
Impact rate: .........................0-4800 bpm
Impact energy: ............................ 1 joule
Span-chuck ............................0.8-10 mm
Weight (without battery charger) ...1,15 kg
Drilling capacity
for concrete ...................... max. 10 mm
for wood .......................... max. 10 mm
for steel ............................. max. 8 mm
Sound power level
(L
pA
) ................... 86,5 dB(A), K
pA
= 3 dB
Sound power level
(L
WA
) ..................97,5 dB(A); K
WA
= 3 dB
h
) ... 8,6 m/s
2
; K= 1,5 m/s
2
Noise and vibration values have been de-
termined according to the standards and
regulations mentioned in the declaration of
conformity.
