• The cross-section of the power
supply cable must not be less
than 2x2,5mm².
• Unsuitable extension cable can
be dangerous. If an extension
cable is used it must be suitable
for outdoor use, and the con-
nection must remain dry and
be routed above the ground.
We recommend using a cable
drum that holds the plug at least
60mm above the ground.
• Wear sturdy footwear to protect
against electric shock.
Initial Operation
In keeping with current regulations
a pressure washer must never be
operated off the drinking water
mains supply without a controllable
backow preventer. A suitable back-
ow preventer in conformity with EN
12729 type BA must be used.
Water that has passed through a backow
preventer is classied as undrinkable.
A backow preventer is available
from specialist retailers.
A system separator (check valve) prevents
the backow of water and detergent into
the drinking water pipeline.
• Employ an ordinary garden hose for
the water intake and ensure sufcient
length.
Setting up
B
• Slide the holder for the detergent
tank / mains cable (16) to the into
the receptor on the appliance side.
• Slide the holders for the steel tube (9)
into the receptors on the back side.
• Slide the holder for the spray gun
(5) to the into the receptor on the
front side.
• Remove the nozzle cleaning pin (6)
from the rear fold-out side of the gui-
dance and slide it into the receptor
on the holder for the spray gun (5).
• Screw the equipment side of the
high-pressure hose connection (1) to
the high-pressure hose connection
(7) on the equipment.
• Insert the high-pressure connection
on the gun side (18) into the spray
gun (14).
• Establish the water supply by con-
necting the rapid-action water sup-
ply connector to the water connec-
tion with sieve insert (
A
10).
C
• Connect to the spray gun (4) by inser-
ting and screwing in the jet tube (2).
• If the jet pipe (2) is mounted,
connect either the adjustable at-jet
nozzle (11) or the high-pressure
nozzle (12) by inserting into the jet
pipe. (2) The attachments snap into
place. To remove the attachments,
press the side lock on the front end
of the jet pipe (2) and pull the at-
tachment forwards to disconnect it.
• Screw in to connect the detergent
container with nozzle (
A
15)
directly to the spray gun (4). With
using the cleaning agent container
with the nozzle (
A
15), pour only
cleaning agent into the container. It
is sucked in automatically.
