Parkside PHD 170 A1 User Manual

5
CY
NIIEGB
6 High-pressure hose on hose reel
7 On/Off switch
8 Control button on the
cleaning agent bottle
9 Cleaning agent container with
nozzle
10 Holder for mains cable
11 Mains cable
12 Wheels
13 Water connection coupling with
strainer insert
14 Water connection
15 Holder for spray gu
16 Jet gun
17 Accessories holder (not visible)
18 Standard Vario nozzle
19 Nozzle cleaning needle
(not visible)
20 Starting lever
21 Locking button
22 Jet lance
23 Lock
24 Turbo dirt blaster
25 Quick connector for garden hose
adaptor
26 High-pressure tting
27 Release button
28 High-pressure tting (gun)
29 Cleaning agent
B
16 Jet gun
20 Starting lever
21 Locking button
Technical data
Pressure washer ........ PHD 170 A1
Mains connection ............. 230 V~, 50 Hz
Power consumption ....................2400 W
Mains cable length ............................ 5 m
High-pressure hose length .................10 m
Weight (without accessories) ........11.4 kg
Safety class ......................................
II
Degree of protection .........................IPX5
Rated/operating pressure (p) ..... 11,5 MPa
Max. permissible pressure (p max) ...17 MPa
General Description
The diagram of the most im-
portant functional elements
can be found on the foldout
side.
Scope of Delivery
Unpack the pressure cleaner and verify the
contents:
- Pressure cleaner with mains cable
- Quick connector for garden hose
adaptor
- Jet gun
- Jet lance
- Turbo dirt blaster
- Standard Vario nozzle
- Rotating wash brush
- Nozzle cleaning needle
- Cleaning agent container with nozzle
- 0.5 l cleaning agent
- Instructions for use
Dispose of the packaging material correctly.
Functional description
The pressure cleaner cleans by means of a
water jet, with a choice of high or low pres-
sure operation.
A detergent can be added if this is required.
For the functions of the operating elements
please refer to the subsequent description.
Ensure that the safety instructions are always
observed!
Overview
A
1 Bow-type handle
2 Rotating wash brush
3 Fixing button on the
washing brush
4 Hose reel crank
5 Hose reel
