Installing Tail
1. Attach the horizontal tail and vertical fi n mount to the fuselage using two
screws (A).
2. Install vertical fi n in vertical fi n mount.
3. Apply clear tape (B) to left and right sides of vertical fi n and fi n mount.
4. Install rudder hinge screw (C)
5. Attach clevises to control horns on rudder and elevator.
6. When needed, disassemble in reverse order.
The tail skid is provided as a
scale feature.
The tail wheel is for improved
steering of the model in runway
takeoffs. The tail wheel is also
recommended for landing on
asphalt or hard surfaces.
Tail Skid
2 X 10mm (2)
3 X 15mm
A
2 X 8mm (3)
A
B
C
Attach tail skid to fuselage and vertical fi n using three screws (A).
Installing Optional Tail Skid
8
