CAN Configuration Mercedes
The wires corresponding to the CAN protocol must be connected correctly to your car stereo’s CAN
information. It is important to follow the wiring diagram for your vehicle. We would advise our
customers to have the interface fitted by a professional.
Connect the white wire corresponding to CAN Low to pin 1.
Connect the green wire corresponding to CAN High to pin 2.
N° Color Description
2
Green CAN High
1
White CAN Low
Not used
Violet K-BUS
Fakra male connexion
Fakra female connexion
