Lower unit mounting Bolt M8 4 18 Nm
Lower unit housing cover Bolt M6 2 8Nm
Anode Bolt M6 1 8 Nm
Water pump housing Bolt M8 4 18 Nm
Water pump base Bolt M8 2 18 Nm
Water inlet Bolt M5 2 5 Nm
Oil drain bolt Bolt M8 1 9 Nm
Oil filler hole Bolt M8 2 9 Nm
Pinion Nut M8 1 25 Nm
Lower unit
Propeller nut Nut M10 1 17 Nm
Steering handle mounting Bolt M8 1 18 Nm
Shift lever bracket Bolt M6 1 4.5 Nm
Clamp bracket Nut M8 1 13 Nm
Upper
Unit
Oil drain bolt Bolt M14 1 27 Nm
Ignition assy Bolt M6 2 8 Nm
General torque
Nut (a) Bolt (b) Torque
8mm M5 5Nm
10mm M6 8 Nm
12mm M8 18 Nm
14mm M10 36 Nm
17mm M12 43 Nm
b
a
13
