5
1.2 General information
1.2.1Specification
Main technical data:
Items Data Items Data
Type of engine Four cylinders,4-stroke Weight (BWL-T) 115Kg
Displacement 996cm
3
Weight (FWL-T) 110Kg
Bore X stroke 65mm×75mm Recommended fuel Unleaded regular gasoline
Gear ratio 1.85（24/13） Fuel tank capacity 24L
Overall length
1383mm(BWL-D/T)
713mm(FW-T)
Recommended engine oil SAE10W30 or SAE10W40
Overall width 427mm Engine oil quantity 2.1L(with oil filter)
Overall height 1435mm Recommended gear oil Hypoid gear oil SAE﹟90
Transom height 508mm
Gear oil quantity 430cm
3
Weight (BWL-D) 113Kg
Spark plug DPR7EA-9
Main performance:
Items Data Items Data
Maximum output
44.1Kw/5500rpm(60HP)
Tightening
torque for
engine
Spark plug 18.0Nm
36.8Kw/5500rpm(50HP) Propeller nut 35.0Nm
Idling speed (in neutral, EFI) 800±50rpm Engine oil drain bolt 18.0Nm
Full throttle operating range 5000~6000rpm Engine oil filter 18.0Nm
Valve clearance IN(cool engine) 0.15~0.25mm Spark plug gap 0.8~0.9mm
Valve clearance EX(cold engine) 0.25~0.35mm
