SETTING CHART -MIG
In Synergic mode enter the welding amperage only the machine will preset the voltage
Amps 65 80 125 150 160 200 220 249
Volts 13 14 14.5 18.5 21 24 24.9 25.1
Amps 65 80 125 150 160 200 220 249
Volts 13 14 14.5 18.5 24 25 26 27.1
Amps 60 80 110 140 160 180 200 250
Volts 14.5 14.8 16.7 18 19.7 22.3 24.5 28.5
Amps 65 80 120 155 180 200 220 250
Volts 15.2 17 19.5 20.1 23.1 23 24.5 28.5
Amps 70 90 130 140 199 220 240 250
Volts 15.2 17 18.9 20.1 21.9 24.5 26.5 28.5
Amps 70 99 148 159 200 225 239 245
Volts 15.5 15.9 17.9 18.5 21.9 24.9 26 27.1
Amps 55 80 100 122 145 150 190 200
Volts 13.5 15.5 13.5 19.2 20.7 22.5 22.9 23.5
Amps 53 83 107 148 165 200 210 220
Volts 13.5 15.2 16.9 20 22.1 22.5 23.5 23.5
Amps 53 100 130 160 180 200 215 225
Volts 13.5 15.2 16.9 20.5 21.1 22.5 23.5 23.9
Amps 53 100 130 160 180 200 220 240
Volts 13.5 15.2 16.9 20.5 21.1 22.5 23.5 24.1
Amps 90 105 11 140 146 166 180 200
Volts 14.7 14.9 15.9 17 17.9 19.3 21.5 23.5
Amps 62 100 125 155 170 200 185 205
Volts 13.5 17 19.5 20.3 20.1 23.5 21.5 23.5
Amps 80 110 130 140 170 200 189 210
Volts 14 17 19.5 20.3 20.1 23.1 22.1 23.5
Amps 80 110 130 140 170 200 195 220
Volts 14 17 19.5 20.3 20.1 23.5 22.5 24.5
Amps 62 83 100 120 146 160 190 210
Volts 13 14.2 15.5 16.5 19.9 22.5 23.8 24.8
Amps 71 91 115 128 140 160 195 210
Volts 14.9 15.9 16.8 17.9 19.9 22.5 24.8 24.8
Amps 69 85 105 125 140 160 195 210
Volts 13.9 15.2 16.6 16.9 19.9 22.5 24.8 24.8
Amps 72 91 115 128 140 160 195 210
Volts 14.9 15.9 16.8 17.9 19.9 22.5 24.8 24.8
Silicon
Bronze
100% Argon
0.9mm
1.0mm
1.2mm
1.2mm
1.0mm
1.2mm
1.0mm
100% Argon
0.8mm
Material
Wire Type
Diameter
of Wire
No Gas
0.9mm
Steel
1.2mm
Mild Steel Solid
Wire
0.8mm
0.9mm
1.0mm
1.2mm
Gasless Flux
Cored Wire E71T-
11
Gas
Flow
Rates
15-25
Stainless
Steel
ER316L Solid wire
AlSi
Aluminum
AlMg
ERCuSI-A
Parameter
Ar98%-CO2 2%
Ar80%-CO2 20% Ar95%-CO2 5%
Plate Thickness
1 mm
1.5mm
2mm
2.5mm
3mm
4mm
5mm
6mm
0.8mm
0.9mm
1.0mm
1.2mm
