WATER BOILING SAFETY
In the event that there is a shortage of water in the boiler or insufficient absorption
of heat from the system due to blocking of circulation, overheating may occur until the
water itself boils.
A manual reset thermostat blocks the pellet loading motor: the thermostat is reset
manually and must be done by pressing the buttons located on the back of the boiler
and covered by screw-on caps.
Info: The intervention of the technical assistance center for boiler overheating is not
covered by the warranty.
3.5 POSITIONING OF THE DEFLECTOR
In the thermostove there is a rectangular deflector (figure 13), this must be
positioned on the fins placed in the upper part of the chamber combustion
(side fins) (figure 14).
(figura 13)
(figura 14)
