PAGE 28
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE T3015/3030DMA
PROFESSIONAL AUDIO & SOUND
®
TM
DIGITAL MUSIC SERIES
3015B PM03W Module 01
NC NOC+-
000
RELAY
VOX
24V DC
100 mA
1 WATT
ZONE 2
ZONE 1
1 VOLT
8
OHM
8
OHM
600
OHM
(MIX BUSS)
EQ LINK
PREAMP
OUT
POWER
IN
L
I
N
P
U
T
1
TEL Prog
CD Off
Off Off
MIC MIC
I
N
P
U
T
2
I
N
P
U
T
3
I
N
P
U
T
1
I
N
P
U
T
2
I
N
P
U
T
2
Z
O
N
E
1
Z
O
N
E
2
E
Q
L
I
N
K
Off
Vox
On
Mute
On
Vox
On
Aux
INPUT
3
INPUT
2
On
INPUT 2
INPUT 1
RVC
MIC/PROG MIC/TEL
REM
BALANCED VOLUMEBALANCEDMUTE
MUTE REMOTE
VOL
HOTGCOM COMGHOT
ATTENUATOR
INPUT 2
PROG
RR
L
INPUT 3 INPUT 2
PROGRAM
UNBALANCED
AUX/CD
ZONE 2
LEVEL
ZONE 1
LEVEL
70V25V80
CLASS 2 WIRING ACCEPTABLE
LINE FUSE 1.6 A 250V
UNSWITCHED 117V 500W MAX.
DIGITAL MUSIC AMPLIFIER
T3015DMA
Power Output 15 W RMS
Supply Voltage 117V 60 Hz
Power Consumption 76 VA
LISTED
COMMERCIAL
AUDIO
EQUIPMENT
30TJ
CUS
®
L
U
®
SET SWITCH TO "3"
LINE
INPUT
PM03W
OUTPUT
LEVEL
70 V
4
COM
3 WATT
Ω
Up to 6 Speakers
may be used
tapped at 0.5 Watt
Each 70 V
0.5
0
70 Volt
Tra ns fo
r
mer
0.5
0
7
0
V
o
l
t
T
ra
n
s
fo
r
m
e
r
0.5
0
7
0
V
o
lt
T
ra
n
s
fo
r
m
e
r
CEILING SPEAKERS
0.5
0
70 Volt
Transformer
0.5
0
7
0
V
o
lt
T
ra
n
s
fo
r
m
e
r
0.5
0
7
0
V
o
lt
T
ra
n
s
fo
rme
r
CEILING SPEAKERS
SATELLITE RECEIVER
PM03W INPUT SOURCE
SELECTOR SWITCH
2
3
E
INSTALLING AND USING THE PASO PM03W POWER MODULE
Fig. 28B - Application 1 Module Wiring Diagram
APPLICATION 1
SPEAKERS - Up to six
70V Speakers tapped at
0.5 Watt may be used.
SOURCE SELECTOR -
The Module Internal
Selector Switch is set to
INPUT 3.The Module will
receive the Satellite
Receiver Program.
Paging or Muting will not
effect the Module Output
LEVEL CONTROL - Use
Module Level Control.
The Amplifier INPUT 3
and the Master Level
Control have no effect on
the Module Output
CAUTION: PRIOR TO INSTALLING THE MODULE IN THE AMPLIFIER READ THE INSTRUCTIONS
IN THE “INSTALLING A MODULE” SECTION OF THIS MANUAL.
MODEL PM03W -
Amplifier Module for DMS Series Amplifiers. Mounts on rear panel port. This is an extremely versatile output mod-
ule that provides a fourth and independent 3 Watt output Zone. Internal Source Switch (3 position) allows to select the source from
Input 2 or 3 (internal connection) of the Amplifier or a separate source by using the Module External Line Input. Power is derived inter-
nally from the Amplifier. 4 ohm and 70 Volt line outputs are provided. NOTE:This Module can only be used with PASO DMS Amplifiers.
Fig. 28 - PM03W - 3 Watt Module Drawings
APPLICATION 1 - In this Application the Module is used to provide Music Distribution (up to 3 Watt Power) only without Paging
Interruption in a separate and independent Zone. The Module Internal Input Source Switch is set to INPUT 3 (Satellite Receiver
Source).
APPLICATIONS: Lobby Areas in Professional and Commercial Buildings, Attached Concession in Auto Service Station C-Store,
Paging-free Areas, additional Zone, etc.
78.00
24.00
11.00
35.00
10.50
21.00
LINE
INPUT
PM03W
OUTPUT
LEVEL
70 V
4
COM
3 WATT
Ω
5.00
78.00
2
3
E
INPUT
SOURCE
SELECTOR
SWITCH
Front View Side View
The figure at left shows the Input Source Selector Switch
located on the Printed Circuit Board of the Module. This
is a 3-position slide Switch which allows to connect the
PM03W Input to the Input 2 or Input 3 of the Main
Amplifier (internal connection) or to the Line Input of the
module for External Connection.
Position 2 = Connects to the Input 2 source the main
amplifier.
Position 3 = Connects to the Input 3 source the main
amplifier.
Position E = Activates the Line Input for use with an
External Source.
When using the Line Input with an External Source the
PM03W can provide an independent 4th Zone with a 3
Watt Power Output (4 ohm or 70 Volt) and a separate
Level Control.
APPLICATION 1
