Paso T3015DMA - Replacement Parts List; Hardware and Transformer Parts; Resistors, Capacitors, and Semiconductors; Controls and Circuit Boards

PROFESSIONAL AUDIO & SOUND
®
TM
DIGITAL MUSIC SERIES
DIGITAL MUSIC AMPLIFIERS
PAGE 31
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICET3015/3030DMA
REPLACEMENT PARTS LIST
AP014044 DMS FRONT PANEL, T3015 - T3030DMA
AR014036 DMS REAR PANEL, T3015 - T3030DMA
AS000133 COVER, T3015 - T3030 DMA MODULE
AT000020 TOP COVER, PA2000 (BLACK)
PR004002 PLASTIC FOOT, NO.1
PK000040 KNOB, 23 DIA. (PASO)
PR001020 CLEAR COVER, SWITCH-BANK T3015-T3030DMA
JT200020 OUTPUT TERMINAL STRIP (04), DT-55-A23W-04
JT200035 INPUTS TERMINAL STRIP (09), DT-29-B01W-09
JT200036 ZONES TERMINAL STRIP (011), DT-29-B01W-11
UO000007 IC NJM4558DD- PREAMPLIFIER U1
UO000018 I.C TA7630P - REMOTE VOLUME U2
UR000005 IC 7824PI - MOH U3
QC000005 TRANSISTOR, C1815 (TP) Q1,2,4,6,11,13,14,
16,17,18
QA000006 TRANSISTOR, A1015GP (TP) Q15
QD000003 TRANSISTOR, 2SD 667C TP. Q5,8,10,19
QD000010 TRANSISTOR, DIP BD139 Q9
QD000012 TRANSISTOR, 2SD1897 - T3015DMA Q7,12
QD000009 TR., 2SD 896 - T3030DMA Q7,12
DZ005160 ZENER DIODE 1/2W C16 TP D15
DZ005220 ZENER DIODE 1/2W C22 TP D5
DB000006 BRIDGE RECTIFIER KBU606 D16
DL001002 LED POWER LIGHT L-113HDT (RED) D606
DN000001 DIODE, 1N4148 D1~4,6~14
RV000009 RK163111R383-50KA-PY INPUTS VR1,2,3
RV000013 RK163111A845-50KB-PY BASS/TREBLE VR4,5
RT000002 RH0611C14J-10KB VR8
RT000012 RH0611C25J-200KB SEMI-VR VR6,7
DMA-VR RK163111R654-50KB-PY MODULE CONTR VR12
PART NO. DESCRIPTION REFERENCE PART NO. DESCRIPTION REFERENCE
TP000101 TRANSFORMER POWER, PT-15D - T3015DMA T1
TO000065 TRANSFORMER OUTPUT, OT-15D - T3015DMA T2
TTP000100 TRANSFORMER POWER, PT-30D - T3030DMA T1
O000064 TRANSFORMER OUTPUT OT-30D - T3030DMA T2
RH000001 THERMISTOR, TD5-A090D TH101,102
RK204002 RESISTOR, KNP-2WS 0.2 OHM R50,63
RM404221 RESISTOR, MOR2WS 220 OHM 15MM R95
CE205472 ELECT. CAPACITOR., 4700UF 35V C54
DL001002 LED POWER LIGHT, L-113HDT (RED)
SW400011 ROCKER, POWER SWITCH RF-1003-BB4-0 S1
CM406113 KNB2520Y0.01UF250VAC CAP METALIZED C101
FH000008 FUSE HOLDER, CQ-206S
FT101016 T FUSE, 5X20 1.6A (5ST 1.6A) - T3015DMA F2
FT101020 T FUSE, S5X20 2A (5ST 2A) - T3030DMA F2
JS000057 AC RECEPTACLE AC-011
WC000003 AC CORD, UL, (SVT-18/3C)
DMS-1 MAIN PCB DMS-1
DMS-2 AMS - MATRIX SWITCHES PCB DMS-2
DMS-3 PREAMPLIFIER PCB DMS-3
DMS-4 MOH - ZONES - VOX RELAY PCB DMS-4
DMS-5 ZONES 1-2 CONTROLS DMS-5
HARDWARE
SEMICONDUCTORS
CONTROLS
TRANSFORMERS
RESISTORS
CAPACITORS
AC POWER SECTION
PRINTED CIRCUIT BOARD COMPLETE
