Pasquali VANTH 5.30 - Page 38

ABCDE
F
min
max
GHLMNPQR
mm
Ø 19,5 50 683 255 R 223
350
475
65°
Ø 19,5 460 455 260 580 95 Ø 22,1
inches
0.77 dia 2.0 26.9 10.0 8.8 R
13.8
18.7
0.77 dia 18.1 17.9 10.2 22.8 3.7 0.87 dia
2
027045
D
E
G
L
M
N
P
Q
F
H
A
B
C
R
R
36
