User Manual IK 150 / 0031 e
© 1997 PAT GmbH · D-76275 Ettlingen · Hertzstr. 32 - 34 · ) ++49 (0) 7243 709-0 · FAX ++49 (0) 7243 709-222 · Email: pat.ettlingen@pat-gmbh.de 16
50 / 150 / 19_0031E.DOC / 19.03.1997 / Rev. C / rk.
7. TROUBLESHOOTING
GENERAL
In case of a malfunction of the system, the display (1) will indicate a code which identifies the sys-
tem malfunction.
The error codes listed in the Malfunction Table will identify various faults which can occur with the
LMI. Following the Malfunction Table are pages which explain each fault and describes the action
which should be taken to correct the fault.
Faults within the electronic microprocessor must be repaired by factory trained service personnel.
When these faults occur, the competent service organization must be contacted.
Malfunctions Table
Error Code Error
E01 Fallen below the radius or above angle range
E02 Radius range exceeded or fallen below angle range
E03 Boom position is out of the permissible working area
E04 Operating mode not existing
E05 Prohibit length range
NOTE:
If there is any Error Code displayed on the console which is not listed in the Malfunctions Table you
should call the Local Distributor.
