User Manual IK 150 / 0031 e
© 1997 PAT GmbH · D-76275 Ettlingen · Hertzstr. 32 - 34 · ) ++49 (0) 7243 709-0 · FAX ++49 (0) 7243 709-222 · Email: pat.ettlingen@pat-gmbh.de 18
50 / 150 / 19_0031E.DOC / 19.03.1997 / Rev. C / rk.
ERROR CODE TABLE
Error Code Error Cause Elimination
E01
Fallen below radius
range or angle range
exceeded
• Fallen below the minimum
radius or gone past the
maximum angle specified in
the respective load chart
due to luffing up the boom
too far
• Luff down the boom to a ra-
dius or angle specified in the
load chart.
E02
Radius range ex-
ceeded or fallen be-
low angle range
• Gone past the maximum ra-
dius or fallen below the
minimum angle specified in
the respective load chart
due to luffing down the boom
too far
• Luff up the boom to a radius
or angle specified in the load
chart.
E04
Operating mode not
acknowledged
• A non existing operating
mode has been selected
• Set the correct operating
mode for the operating state
in question
E05
Prohibited length
range
• Boom has been extended
either too far or not far
enough, e.g. if it is prohib-
ited to go beyond a certain
maximum boom length or
with load curves for jibs
where the main boom has to
be extended to a certain
length
• Extend/retract boom to the
correct length
• Length sensor adjustment
has changed, e.g. the cable
slid off the length sensor
reel.
• Retract boom. Check the
prestress of the cable reel
(cable must be taut). Open
the length sensor and care-
fully turn the length sensor
pot counterclockwise until
the detent by means of a
screw driver
• Clutch between length sen-
sor pot and drive is defec-
tive
• Replace the complete clutch
including drive wheel and
adjust length sensor pot as
described above
• Failure of +5V supply of
analog part of analog board
• Check +5 V supply. Ex-
change main board in case
of voltage failure or break-
down when loaded with 50
ohms approx.
• Cable between central unit
and length sensor is defec-
tive or disconnected.
• Check cable and plugs, re-
place, if need be.
