Error Code Error Cause Elimination
E45
Redundancy error in
the A/D conversion
• The A/D converter on the
processing board and the
redundant A/D converter in
the CPU 80C537 provide
different results.
• Replace processor board.
E46
Error in the A/D con-
verter uPD 7004 of
the processor board.
• No acknowledgment of the
A/D converter uPD 7004
• Replace processor board.
E47
Error in the monitored
write/ read memory.
The CRC verification
of the monitored
write/read memory
provides an incoher-
ent result
• The CRC sign of the moni-
tored write/read memory is
wrong
• The buffer battery is de-
charged (< 2V at 1kOhm).
• Processor board defective.
• Restart the LMI
• Replace buffer battery on
the LMI main board
• Replace processor board.
E48
Cyclic RAM test: er-
ror in the internal
write/read memory
(RAM) of the com-
puter component
80C537
• Computer component
80C537 defective
• CPU module defective
• Processor board defective.
• Replace computer compo-
nent 80C537.
• Replace CPU module
• Replace processor board
with CPU module.
E51
Error in the crane
data EPROM or
EEPROM.
• No valid data in the crane
data EEPROM.
• Memory module wrongly
bridged.
• Crane data EPROM defec-
tive
• Load crane data EEPROM
containing valid data.
• Bridge memory module acc.
to memory type
• Replace crane data EPROM
E52
Error in load chart
PROM.
• Memory module wrongly
bridged.
• Load chart EPROM defec-
tive.
• Bridge memory module acc.
to memory type.
• Replace load chart EPROM
E56
Error in crane data
EEPROM.
• Memory module wrongly
bridged.
• Crane data EEPROM de-
fective
• Bridge memory module acc.
to memory type
• Replace crane data
EEPROM
